Description
SMC MAGNET SYSTEM
With a pole piece constructed entirely from SMC, surrounded by a slitted copper cap, and enclosed within a large ferrite magnet, the effect of the SMC is focused and maximised, and reduces distortion as never heard before.
SOFT DOME TWEETER
With a clear heritage from our high-end series, the lightweight dome tweeter offers best in class resolution.
WOOD FIBRE CONES
Using a wood fibre cone gives the in-house build woofer a light, rigid and randomly uneven membrane. Making it easy to move ensures even piston like movements and reduces the possibility of surface resonance greatly.
CABINET CONSTRUCTION
Dividing the mid-range and basse drivers into separated chambers enables us to individually tune every driver to its specific frequency range to maximise the woofer output.
SMC
All variants in the series feature the DALI SMC magnet system which reduces distortion as never heard before. Part of the “secret” is the individually coated magnetic granules that make it possible to mould a strong magnet that’s not electrically conductive.
TWEETER
The ultra-lightweight soft dome tweeter used in the RUBICON 2 is designed to reach higher into the very high frequencies. Higher than normal for at soft dome used in a DALI hybrid tweeter. This is done since the soft dome tweeter is required to work on its own in the RUBICON 2.
The voice coil used in the RUBICON 2 is furthermore designed to be very light and agile in order to achieve a broader bandwidth. This lighter voice coil is placed inside a powerful ferrite magnet that keeps a tight control of its movements.
WOOFER
The cone used in the RUBICON 2 draws upon the heritage from the EPICON technologies, and has a light, rigid and randomly uneven structure. This lower the complexity of the central part of the motor, ensures even piston like movements, reduces the possibility of surface resonance greatly and creates an extremely low distortion within the RUBICON 2.
The soft low-loss rubber surround is designed and bespoke specifically for the RUBICON 2, and all of the components are situated in an aluminum chassis designed for maximum airflow around the cone and magnet system.
DALI RUBICON 2 SPECS
Product series RUBICON
Frequency Range (+/-3 dB) [Hz]         50 Р26.000
Sensitivity (2,83 V/1 m) [dB]    87.0
Nominal Impedance [ohms]     4
Maximum SPL [dB]      107
Recommended Amplifier Power [W]    40 Р150
Crossover Frequency [Hz]       3,1
Crossover Principle     2-way
High frequency driver, Quantity           1 x 29 mm
High frequency driver, Diaphragm type           Soft Textile Dome
Low frequency driver, Quantity¬†¬†¬†¬†¬†¬†¬†¬†¬†¬†¬† 1 x 6¬Ω”
Low frequency driver, Diaphragm type            Wood Fibre Cone
Connection Input         Single Wire
Magnetic Shielding      No
Recommended Placement      Shelf or stand
Recommended Distance From Wall [cm]        20 Р120
Dimensions With Base (HxWxD) [mm]            353 x 195 x 335
Accessories Included   Manual
Micro Fibre Cloth
Rubber Bumpers
Weight [kg]      8.0
